Coatings

Beam Splitter Coatings

1. Laser Line Polarization Beamsplitter

High reflection for s-polarized and antireflection for p-polarized for laser application.



                                        Single wavelength polarization beamsplitter coating
                                   Rs>99.5@632.8nm & Rp<5%@632.8nm, 45deg. incidence


2. Broadband Polarization Beamsplitter

Wide wavelength bandwidth provide high reflection to s-polarized and antiflection to p-polarized.

                                             Broadband polarization beamsplitter coating
                           Rs>99%@450~650nm & Rp<5%@450~650nm, 45deg. incidence


3. Dichroic Beamsplitters Mirrors

These coatings can separate the laser fundamental and the pump wavelength, or the fundamental and the second harmonic.

They are specific applied to laser mirror.



                                      Short-wave pass beamsplitter coaitng
                            R>99.8@1064nm & R<5%@532nm, 0deg. incidence





                                                   Long-wave pass beamsplitter coating
                                                  R>99.8%@532nm & R<5%@1064nm


Other wavelengths and incident angles are also available.
